Industrial Grade Power Pendant Outlet Boxes
KH Industries Power Pendant Outlet Drops deliver safe, reliable overhead power distribution to manufacturing assembly lines, MRO facilities, and industrial workstations. Industrial grade rubber portable outlet boxes, non-metallic, non-conductive, and code-compliant, bring accessible power directly to the point of use.
Outfitting a line of workstations with power pendant outlet boxes? Talk to KH Industries.
Bringing overhead power to an assembly line, MRO bay, or bank of workstations? Request a quote for power pendant outlet boxes matched to your amperage, cord length, connector, and application requirements.Power Pendant Outlet Box
Mesh grip, rubber housing, integrated strain relief. See the details that let KH Industries power pendant outlet boxes hang safely and hold up shift after shift.
Close, but not the exact fit?
You've dialed in your spec. If the exact length, gauge, connector, or rating isn't listed, we'll configure it for you. Real engineers, quick turnaround.
How to Select the Right Power Pendant Outlet Box
Choosing the right power pendant outlet box comes down to three things: the electrical load it needs to support, the drop length and configuration, and the housing and construction. Match each to your workstation and connected electrical load for overhead power that stays accessible and out of the way.
Power & Connections
Start with your connected electrical load. Power pendant outlet boxes are available in 15A and 20A configurations, with four outlets on standard models. Options include 125V configurations and 125/250V twist-lock configurations, depending on the model. Plug configurations include NEMA 5-15P, NEMA 5-20P, and NEMA L14-20P.
Share your connected electrical load, and KH Industries will help confirm the appropriate amperage, receptacles, and connector.
Drop Length & Suspension
Choose the drop length that reaches your point of use. Standard configurations are available with 25' or 50' of 12 AWG SOOW cord, with other configurations available by request. A mesh strain-relief cord grip helps prevent cable pullout and control the cord's bend, while the integrated strain-relief system is molded into the outlet box.
Tell KH Industries your mounting requirements and the team can help identify the appropriate drop configuration.
Housing & Environment
Power pendant outlet boxes are made from non-metallic, non-conductive materials and are designed to help protect against electrical shock. KH Industries designs these products to comply with applicable OSHA and NEC requirements and builds them with CSA/UL components.
Describe your application and KH Industries can help identify the appropriate configuration.
THE RIGHT POWER PENDANT OUTLET BOX
BRINGS POWER TO THE POINT OF USE.
KH Industries power pendant outlet boxes deliver overhead power directly to the point of use. Built from non-metallic, non-conductive materials and prewired with SOOW cord, they feature mesh strain-relief cord grips and an integrated strain-relief system. KH Industries designs these products to comply with applicable OSHA and NEC requirements and builds them with CSA/UL components. Current configurations are made in the USA. If you need a different configuration, KH Industries can modify the length, gauge, connector, or rating to fit the application.
Choose a drop long enough to reach the work surface comfortably from your overhead mounting point, with a little slack. Standard configurations are available with 25' and 50' lengths of 12 AWG SOOW cord, with other configurations available by request. Tell KH Industries your mounting requirements and the team can help identify the appropriate configuration.
Choose the amperage and plug configuration that match your connected electrical load and circuit requirements. KH Industries offers 15A and 20A configurations, including NEMA 5-15P and NEMA 5-20P options, as well as 125/250V configurations with NEMA L14-20P on applicable models. Check the specific product configuration for the available receptacles and connector.
Each standard configuration provides four outlets, allowing multiple tools or devices to connect at the same time. The total connected electrical load must remain within the applicable circuit and outlet-box rating. Check the specific configuration for its amperage and receptacle specifications.
Yes. KH Industries power pendant outlet boxes are made from non-metallic, non-conductive materials and are designed for industrial power distribution. Current product configurations are designed to comply with applicable OSHA and NEC requirements and use CSA/UL components. Check the specific product configuration for application requirements, or contact KH Industries for assistance selecting the appropriate build.
Yes. KH Industries offers configurable power pendant outlet boxes and can modify factors such as cord length, gauge, connector, and rating to suit the application. Request a quote for the configuration you need, or Contact KH Industries to discuss your requirements.
